Mobile Payment Automatic Barcode Scanner 2D CMOS Automatic Barcode Reader

Mobile Payment Automatic Barcode Scanner 2D CMOS Automatic Barcode Reader

    • Mobile Payment Automatic Barcode Scanner 2D CMOS Automatic Barcode Reader
    • Mobile Payment Automatic Barcode Scanner 2D CMOS Automatic Barcode Reader
  • Mobile Payment Automatic Barcode Scanner 2D CMOS Automatic Barcode Reader

    Product Details:

    Place of Origin: China
    Brand Name: DYscan
    Certification: FCC, RoHS, CE, IEC, FAD
    Model Number: DP8120

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: L120mm*W80mm*H120mm
    Delivery Time: 5
    Payment Terms: T/T, Western Union
    Supply Ability: 10000
    Contact Now
    Detailed Product Description
    Scan Type: CMOS Dimension: L67.7mm * W67.7mm * H35.3mm
    Color: White Decoding Speed: 60CM/S
    Power Supply: DC 5V@220mA(work) Scan Angle: Roll360°,Pitch±60°,Skew±60°(PCS90%,Code 39,10mil/0.25mm)

    0mm-100mm 2D CMOS Omni Directional Barcode Scan Platform For Mobile Payment



    Product Description


    DP8120 is a Plug and play ,easy to operate no need any driver.



    Automatic wake up function,Support multiple languages.



    Multi-line rastering scan pattern ,more accurate and effecient.



    Extra loud beeper,confirms positive decode feedback in noisy environments.



    Features

    ☆ Big power , suitable for noisy environment


    ☆ Original wide-angle , let scanning angle being bigger and wider


    ☆ USB free driver, plug and play.Decode most 1D and 2D codes.


    ☆ Automatic wake up function,Support multiple languages.


    ☆ Support Multil-language.12 month long time warranty.


    ☆ Elegant, good stability, suitable for various commercial uses.





    Application



     Mobile payment      Supermarket      Courier





    Parameter



    Physical Parameter
    Weight 95g(without cable)
    Dimension L67.7mm * W67.7mm * H35.3mm
    Interface type USB,DB9
    Communication way USB(USB-KBW,USB-COM),RS232
    Power supply DC 5V@220mA(work)
    Performance
    Scan type CMOS
    Light source Red light LED 625±10nm(aim),6500K LEDs(lighting)
    CPU 32-bit
    Resolution 640*480
    Resolution ≥4mil/0.1mm(PCS90%,Code 39)
    Scan tolerance 60CM/S
    Depth of field 0mm-100mm
    Scan mode Manual,Auto sense
    Scan angle Roll360°,Pitch±60°,Skew±60°(PCS90%,Code 39,10mil/0.25mm)
    Print contrast signal ≥20%
    Ambient light Dark, Indoor natural light
    Symbologies 1D:UPC-A,UPC-E,EAN-8,EAN-13,Code 128, GS1-128, Code 39,Code 93,Code 11,Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5,Standard 2 of 5(IATA),Codabar(NW-7),MSI Plessey,RSS,China Post,Telepen,etc.
    2D: QR Code, Data Matrix,PDF417,Maxicode,Aztec,Hanxin,etc.
    Environmental
    Operating temperature -20℃ to 50℃
    Storage temperature -40℃ to 70℃
    Humidity 5% to 95%(non-condensing)
    Drop Height 1.5m
    Transport vibration Test 10H@125RPM
    Depth of field
    4MIL 0-30mm (PCS90%,Code 39)
    13MIL 5-80mm (PCS90%,EAN-13)
    20MIL 5-100mm (PCS90%,Code 39)
    10MIL 5-20mm (PCS90%,Data Matrix)
    20MIL 0-100mm (PCS90%,QR Code)
    Mountings list
    Data cable USB cable,used to connect the DP8120 and the information receiving host
      RS232 cable,USB cable,used to connect the DP8120 and the information receiving host, USB for charging




    Packing & Delivery


    Package Size :80*105*107mm

    Size:67.7*67.7*35.5mm

    Weight:≈95g(without cable)
