    Product Details:

    Place of Origin: China
    Brand Name: DYscan
    Certification: FCC, RoHS, CE, IEC, FAD
    Model Number: DP8300

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: L220mm*W185mm*W115mm
    Delivery Time: 5
    Payment Terms: T/T, Western Union
    Supply Ability: 10000
    Contact Now
    Detailed Product Description
    Scan Mode: Auto Sense Interface Type: USB,DP9
    Resolution: ≥4mil/0.1mm(PCS90%,Code 39) Power Supply: DC 5V@250mA(work)
    Depth Of Field: 0mm-500mm Operating Temperature: -20℃ To 50℃

          Powerful Scanning Efficiency & Breakthrough Scanning Desktop Barcode Scanner



    Product Description


    It is With superb first-pass scan read rates from any angle, it is an in-counter scanner designed to give retailers a faster check-out process and an uncluttered countertop appearance.



    Integrated Electronic Article Surveillance (EAS) connectivity enables cashiers to simultaneously capture the bar code and deactivate the EAS tag.



    Omni-directional scanning allows data capture regardless of how the scanned object is positioned. The scratchproof sapphire glass/stainless steel option enhances data capture reliability in more demanding environments



    Features

    OEM and ODM service are offered


    ☆ Read all 1D 2D mainstream barcodes in the market easily. (4mil)


    Can apply to the fields like wharf,airport,commercial,logistics,medical etc.


    Automatic idle when not using,energy-consuming


    USB interface ,easy to use,Plug and play


    Powerful scanning efficiency & Breakthrough scanning performance




    Application


    ▅ Mobile payment ▅ Supermarket  ▅ Courier



    Parameter



    Physical Parameter
    Weight 725g(without cable)
    Dimension L88mm * W150mm * H150mm
    Interface type USB,DB9
    Communication way USB,RS232
    Power supply DC 5V@400mA(Work)
    Performance
    Scan type CMOS
    Light source Red light LED 625±10nm(aim),6500K LEDs(lighting)
    CPU 32-bit
    Resolution 1280*800
    Resolution ≥4mil/0.1mm(PCS90%,Code 39)
    Scan tolerance 60CM/S
    Depth of field 0mm-500mm
    Scan mode Auto sense
    Scan angle Roll360°,Pitch±60°,Skew±60°(PCS90%,Code 39,10mil/0.25mm)
    Print contrast signal ≥20%
    Ambient light Dark, indoor natural light
    Symbologies 1D:UPC-A,UPC-E,EAN-8,EAN-13,Code 128, GS1-128, Code 39,Code 93,Code 11,Interleaved 2 of 5,matrix 2of 5,industrial 2 of 5(IATA) Codabar(NW-7),MSI Plessey ,RSS, China Post etc.
    2D: QR Code, Data Matrix,PDF417,Maxicode,Aztec,Hanxin,etc.
    Environmental
    Operating temperature -20℃ to 50℃



    Storage temperature -40℃ to 70℃
    Humidity 5% to 95%(non-condensing)
    Drop Height 1.5m
    Transport vibration Test 10H@125RPM
    Depth of field
    5MIL 10-40mm (PCS90%,Code 39)
    13MIL 10-200mm (PCS90%,EAN-13)
    20MIL 10-300mm (PCS90%,Code 39)
    40MIL 100-400mm (PCS90%,Code 39)
    20MIL 10-180mm (PCS90%,QR Code)
    Accessories list
    Data cable USB cable,used to connect the DP8300 and the information receiving host
      RS232 cable, used to connect the DP8300 and the information receiving host, USB for charging



    RFQ

    1. What's the shipping way ?
    There are DHL,Fedex,TNT, UPS.
    We also can ship the goods by your shipping account or other express agent you provided.

    2. What's the payment way ?
    We accept PayPal ,T /T,LC , Western Union , MoneyGram.

    3. How about your product warranty ?
    Our officially promised warranty time is 1 years after delivery.

    4. How can I get the goods ?
    We will choost the fast , safe , and cost saving way to send goods to you.
    With well packed carton by foam and plastic film to advoid goods damage.

    5. If I come across any problem during product using ,where I can get the support ?
    We support you technically 24h.please send all your questions to us. And we will give the professional,patient,expliantion by email or call in time.
