Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired

Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired

  • Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired
  • Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired
  • Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired
  • Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired
  • Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired
  • Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired
Hands Free 2D 1D Omnidirectional Barcode Scanner USB Wired
Product Details:
Place of Origin: China
Brand Name: DYscan
Certification: CE ROHS FCC IEC
Model Number: DP8521P
Payment & Shipping Terms:
Minimum Order Quantity: 2pcs
Price: negotiable
Packaging Details: 595*380*235mm/10pcs /Carton
Delivery Time: 5-7days
Payment Terms: T/T, Western Union,PAYPAL
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Scan Type: CMOS Resolution: ≥3mil/0.076mm(PCS90%,CODE 39)
Decoding Speed: 1280×1024 Depth Of Field: 0mm~1000mm
Scan Mode: Continuous Print Contrast Signal: 20%PCS
Symbologies: 1D 2D Dimension: 151.5mm L × 84mm W × 153mm H
Interface Type: USB-KBW、RS232 Weight: 475g(without Cable)
High Light:

2D 1D Omnidirectional Barcode Scanner

,

Hands Free Omnidirectional Barcode Scanner

,

USB Wired Capture Barcodes Scanner

2D Portable Barcode Scanner



DP8521Pro is a 1.3 mega pixel high performance 2D desktop scanner with advanced CMOS image recognition technology.

It can easily read paper, goods, screens and other media 1D 2D barcodes.

Widely used in large supermarkets, restaurant, chain stores, and grocery stores.



Feature



☆ Wide window design, auto sense scanning.

☆ 2d image technology, read paper, plastic, screen 1D 2D barcodes, etc. easily.




Performance



Scan Type CMOS
Light Source light: red LED,wavelength 525nm
CPU 32-bit
Resolution 1280×1024
Resolution ≥3mil/0.076mm(PCS90%,CODE 39)
Decoding speed 120CM/S
Depth of field 0mm~1000mm
Scan Mode Continuous
Indicator buzzer
Scan angle Roll:±360°,Pitch:±60°or greater,Yaw:±70°or greater)
View angle Horizontal 40°× Vertical 30°
Print Contrast Signal 20%PCS
Ambient Light Dark environment, indoor natural light
Symbologies
1D:Codabar,Code39,Code32,Interleaved 2 of 5(ITF25),Industrial 2 of 5,Matrix 2 of 5,Code93,Code11,Code128,Gs1-128,UPC-A,UPC-E,EAN/JAN-8,EAN/JAN-13,ISBN,ISSN,GS1 databar,GS1 databar limited,GS1 databar expanded,ISBT,MSI,Febraban(Brazilian bank code)

2D:PDF417,Micro PDF417,QR Code,Micro QR,Data Matrix,Aztec



Physical Parameter



Weight 475g(without cable)
Dimension 151.5mm L × 84mm W × 153mm H
Communication Mode
USB-KBW,RS232
Interface Type USB, RS232
Power Supply

DC 5V@290mA(work)



Environmental



Operating temperature -20℃ to 55℃
Storage temperature -20℃ to 60℃
Humidity 5% to 95%(non-condensing)
Drop Height 1.2m
Transport Vibration Test 10H@125RPM
