Name: Mini Bluetooth Barcode Scanner DI9010-1D 300 Scans/Sec Wireless
Brand: Shenzhen DYscan Technology Co., Ltd
Price: 28.00 USD
Availability: InStock

Home Products Wireless Barcode Scanner

Mini Bluetooth Barcode Scanner DI9010-1D 300 Scans/Sec Wireless

Product Details:

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Detailed Product Description

Model NO.:	DI9010-1D	Interface Type:	2.4G Bluetooth
Scan Speed:	300 Scans/sec	Scan Element:	CCD
CPU:	32bit	Resolution:	3mil/0.076mm(PCS90%,Code 39)
Depth Of Field:	60mm-500mm	Scan Mode:	Manual, Continuous, Auto Sense
Prompting Mode:	LED Indicating Lamp Buzzer	Print Contrast:	25%PCS
Weight:	35g Without Cable	Charging Cable:	Type C
Battery Capacity:	350mAh	Storage:	2MB
Wireless Distance:	Bluetooth 30meters
Highlight:	Mini Bluetooth barcode scanner , Wireless barcode scanner 300 scans/sec , Bluetooth barcode scanner DI9010-1D

High Performance Mini Bluetooth Barcode Scanner with Laser Recognition Technology

Product Overview

The DI9010-1D is a compact, high-performance wireless barcode scanner featuring advanced CCD laser recognition technology. This finger-wearable ring scanner delivers exceptional scanning speed and accuracy for various industrial and commercial applications.

Key Specifications

Attribute	Value
Model NO.	DI9010-1D
Interface Type	2.4G Bluetooth
Scan Speed	300 scans/sec
Scan Element Type	CCD
CPU	32bit
Resolution	3mil/0.076mm(PCS90%,Code 39)
Wireless Transmission Distance	Bluetooth 30meters
Battery Capacity	350mAh
Weight	35g Without Cable

Technical Features

High-speed scanning at 300 scans per second
Multiple scan modes: Manual, Continuous, Auto Sense
LED indicating lamp and buzzer for operation feedback
Type C charging cable for convenient power supply
Compact finger-wearable design weighing just 35g
2MB storage capacity for data logging

Physical Parameters

Parameter	Specification
Light Source	White LED (auto-adjusting brightness), Green aiming LED (525nm)
Startup Time	750ms
Reading Angle	Roll: ±360°, Pitch: ±60°, Yaw: ±70°
Motion Tolerance	25cm/s
Print Contrast	25%PCS

Supported Symbologies

1D Codes: Codabar, Code39, Code128, UPC-A/E, EAN-8/13, GS1-128, and more
2D Codes: PDF417, QR Code, Data Matrix, Aztec

Product Images

Frequently Asked Questions

Q: What is the warranty period for this barcode scanner?

A: The product comes with a 12-month warranty from DYscan.

Q: Does this scanner require driver installation?

A: No, our scanners support plug-and-play functionality across Windows, Mac OS, iOS, Linux, and Android systems.

Q: Can you provide OEM/ODM services?

A: Yes, we offer OEM services including custom branding and packaging, as well as ODM support through our technical team.

Quality Assurance

All DYscan products undergo rigorous testing including wire bend tests (1 million cycles), button durability tests (1 million presses), and comprehensive performance verification. Our scanners meet CE, FCC, and ROHS certification standards.
